5100 Plus 套裝避震器組

5100Plus系列是由5100Co版本升級而來是5100系列的最高版本配置，同時具有倒置式筒身設計(在部分雙對應雙A臂懸吊套件多數為正置)與12個點擊阻尼軟硬調整範圍 ，

前軸採用直捲式彈簧搭配鋁合金魚眼上座 可降低車輛的行駛高度約3-5公分 後軸使用Coil over設定(可選配鋁合金上座及魚眼固定套件)

5100Plus 是一款街道兼容賽道使用的高性能懸吊系統

優點包括：

• 選用鋁合金魚眼上座容許更大角度調整(限定車種），避震器作動角度更加靈活
• 搭配直捲式彈簧可以有效的抑制側傾
• 後軸彈簧選項(Coil over) 能獲得較佳的舒適性與循跡性
• 後軸可搭配鋁合金上座及魚眼固定套件*選購
• AST專屬防傾桿拉桿（李仔串）可以增加防傾桿的鋼性(限定車種）*選購
• 荷蘭原廠手工組裝
• 施工安裝容易
• ​採用高壓氮氣充填的浮動活塞設計可消除油室內的氣泡(擁有更穩定的阻尼作動)
• 14mm直徑的內部避震器軸芯
• 44.5mm直徑的倒置避震器外軸芯
• 倒置式鋼製避震器外軸芯
• 高性能避震系統
• 避震器使用低磨擦密封組件
• 回彈阻尼可單獨調整(12段)
• 調節旋鈕永久安裝在避震器上(不需要使用特殊工具)
• 強化的筒身支架橡膠襯套。
• 可選配DLC（類鑽碳）塗層軸
• 可選DDP活塞（雙活塞）
• 可選彈簧Kg數(磅數)
• 可選配訂制閥門
• 一年保固(嚴禁賽道使用) 賽道使用只提供保修服務

Sportline 2 (5100 Series Plus)

The 5100Plus series of shock absorbers feature an inverted barrel design with 12 click adjustment ranges,adjustable damping, soft and hard, and a high-low adjustable design with a straight-roll spring that reduces the vehicle's ride height by approximately 3-5 cm in most vehicles.The front axle uses an aluminum alloy fisheye upper rear axle with an integral custom spring option and an AST-specific anti-roll bar (limited vehicle type).

How a Monotube design works?

Monotube design essential for performance, The oil and nitrogen are separated by a floating piston, and
allows the use of a larger piston, increasing the damper performance and sensitivity felt by the driver, all this
added together produces more grip, gives more control and driver feedback from your vehicle.


What is a rebound adjustment?

Rebound controls the rate of extension of your shock absorber. By changing the rebound you can directly
change the characteristics of the vehicle.

Technical specifications:

• Floating piston design with high pressure nitrogen eliminates air bubbles in the oil chamber.
• 14mm diameter internal shaft.
• 44.5mm diameter shock absorber core.
• High performance racing suspension system .
• New low friction seal assemblies on all AST dampers.
• Rebound can be adjusted separately.
• The adjuster knob is permanently mounted on the damping.
• Optional aluminum alloy fish eye seat.
• Optional DLC (Diamond-like Carbon) coated shaft.
• Optional DDP piston (double piston).
• Optional custom valve.
• Optional rear axle integral custom spring (limited vehicle type).
